SCHILLER FRED EASYPORT DEFIBRILLATOR

Description

The SCHILLER FRED easyport (also available in the “plus” version) combines pocket‑size portability with advanced resuscitation capabilities:

• Lightweight & Compact: Just 0.49 kg including the battery, making it the smallest AED globally .

• User‑friendly “1‑2‑3” Workflow:

  1. START – press the green button to power on; performs a self‑test.

  2. ANALYZE – apply the pads (adult/paediatric), press the blue button to begin ECG analysis.

  3. SHOCK – if a shockable rhythm is detected, the orange button lights up; press it to deliver. Voice and screen prompts guide throughout .

• Real‑time CPR Support: Includes metronome and ARGUS LifePoint feedback sensor to ensure effective chest compressions. A large, clear LCD displays CPR instructions and ECG waveform.

• Multipulse Biowave Technology: Delivers biphasic, pulsed shocks optimized for maximum efficacy at low energy levels.

• Durability & Connectivity: IPX4 water resistance, automatic self‑tests, operates on disposable or rechargeable batteries, with data transfer via USB/Bluetooth. Optional memory card records ECG for up to 30 minutes and logs events.

• Versatility: Offers intuitive paediatric mode using the same pads, plus manual and fully‑automatic versions. The “plus” variant adds a color LCD, child‑mode button, and varying energy protocols. Dimensions: 46 × 150 × 143 mm; weight ~870 g with battery/pads
